Spacer block D28 U-Form L2000, steel hardened 200 x 200 mm

For use as a table extension
Clamping surface: Five-sided
100 x 100 mm diagonal grid, with grid lines
Spacer blocks with hardened surfaces are protected against weld spatter adhesion, thus reducing wear

Additional options for system D28:

Optimum use on rail system in conjunction with D00-10017-xxx. Or to build a frame using D28-06003-000 connecting bushes
For use as a table extension
From a length of 1 m, option to mount an additional PL28-10010-xxx support leg in conjunction with 00060364 or 00060369 base plate
Bore spacing for fitted shoulder screws, bottom, matched to base rail width 1000, 2000, 3000 and 4000 mm

price on request

plus VAT
