PPC countersunk bolt D28 short

  • PPC countersunk bolt D28 short
  • PPC countersunk bolt D28 short
  • PPC countersunk bolt D28 short
  • PPC countersunk bolt D28 short

Product description


  • Made especially for DEMMELER electric screwdrivers
  • Used for simultaneous clamping of two system components
  • Easy, convenient clamping through optimised force distribution in the expansion segments
  • Minimal susceptibility to dirt due to polygonal shape
  • Standard at DEMMELER for a long service life: High-strength, hardened and ground
  • With optimum force distribution, DEMMELER opens up a new dimension of possible applications
  • Countersunk bolts may only be used in bores and not in oblong holes
  • The short version connects 2 system components together or 1 system component on the welding table
  • The specified loads must not be exceeded when using the clamping bolts. The discharge of welding voltages, unfavourable leverage and impacts have to be avoided
price on request

plus VAT

System:

Amount:

Item number: D28-06027-000

Technical data


Diameter A in mm 28-0.02
B in mm 32
Clamping range 41-47
Tensile force in kN 10
Shear force in kN 200
Tightening torque in Nm 50
Approx. weight in kg 0.3
